Product DescriptionCompany Info.<>
- Model:
- PO9644
- Structural form:
- Floating ball tee
- Material:
- Carbon steel
- Connection form:
- Flange
- Nominal diameter:
- 50 mm
- Pressure environment:
- Normal pressure
- Operating temperature:
- Normal temperature
- Driving mode:
- Pneumatic
- Flow direction:
- Commutation
- Standard:
- National standard
- Parts and accessories:
- Accessories
- Use:
- Commutation
- Types:
- Three-way
- Action object:
- Pump
Pneumatic Y-type three-way ball valve 45 degrees 135 degrees Overview
Pneumatic Y-type three-way ball valve 45 degrees 135 degrees into each other 135 two kinds of valve body structure, Y-type three-way ball valve channel flat. Equipped with electric actuators, pneumatic actuators actual automation control.Pneumatic Y-type three-way ball valve 45 degrees 135 degrees standard technical parameters
valve body
Nominal diameter: DN50-DN300
Body material: WCB, 304, 316
Connection mode: flange type
Pressure rating: PN1.6-4.0MPa
Structural form: Y-type 120 degrees, Y-type 135 degrees
valve assembly
Seat seal: PTFE: -30℃~180℃
PPL ：-30℃~250℃
Hard seal: -30℃~450℃ Cemented carbide: surface spray welding, tungsten nitride
Valve core material: 304, 316, 316; hard seal ball core surface using spray welding, tungsten nitride
Stem material: 304
Suitable medium: powder, water, gas, etc.
performance
The flow channel forms 120-degree switch, the flow channel is flat, the resistance is small, and the flow capacity is strong.
No medium retention
Soft seal: 250 degrees
Hard seal: 425 degrees
Leakage: Zero leakage
Return: 2.5%
design and manufacture standards
Design and manufacture: GB/T12238-2008
Connection standard: JB/T 79.1-1994
Structure length: GB/T12221-2005
Pressure test: GB/T13927-2008
pneumatic actuator
Double-acting: ventilation on, ventilation off, air source fault to maintain the current position
Single-acting gas open: ventilation open, dead close, gas source fault close
Single-acting air-off type: vent off, dead open, air source fault open
Optional accessories: reversing solenoid valve, limit switch, air filter pressure reducing valve, electric positioner, handwheel mechanism, position keeping valve
Explosion-proof can be selected for electrical part
